SPECIFICATIONS







Displacement: 224cc



Material: Aluminum

Maximum Torque: 9N.m



RPM: 3600rpm

Recommended Gasoline: #92 or Above

Type: 4-Stroke, Single Cylinder, Air-cooled



Description

An exceptional outboard engine is the heart of a watercraft's performance, significantly elevating your boating experience to higher levels of smoothness and safety. Its efficient and reliable operation ensures every journey on the water becomes an unforgettable adventure, delivering not only an exhilarating sense of freedom but also the feeling of wide exploration possibilities.









Specification



Color: Black

Material: Aluminum

Type: 4-Stroke, Single Cylinder, Air-cooled

Recommended Uses For Product: Outdoor

Mounting Type: ‎Transom Mount

Starting Method: Manual Pull Start

Recommended Gasoline: #92 or Above

Maximum Torque: 9N.m

Displacement: 224cc

RPM: 3600rpm

Idle Speed: 1800 ±150 rpm

Max. Speed: 19km/11.81mile/h

Bore x Stroke: 72 x 55mm / 2.83 x 2.17in

Recommended Power Output: 4.2kW / 3600rpm

Maximum Output Power: 4.2kW (9.0hp)

Fuel Capacity: 1.3-1.5L/0.34-0.4Gal

Engine Oil Capacity: 0.6L/0.16Gal

Compression Ratio: 8.7:1

Spark Gap: 0.6-0.8mm

Exhaust Valve Clearance: 0.15-0.2mm

Propeller Diameter: 20cm/7.87in

Applicable Boat Size: 4.57-6m/15-20ft

Product Size: 46*36*105cm/18.11*14.17*41.34in

Package Size: 121*52*40cm/47.64*20.47*15.75in

Gross Weight: 24kg/52.9lbs

Net Weight: 20.6kg/45.42lbs









Package Included



1* 4-stroke Outboard Motor

1* English Manual

Other Needed Accessories







Key Features



Engineered for Durability: Constructed from premium aluminum, this product is designed to be robust, and rust-inhibiting, providing a reliable and enduring solution.



Powerful Performance: Delivering 9.0 horsepower from a 224cc engine, it ensures strong propulsion and smooth navigation for your watercraft. With a top speed of 11.81 mph and efficient fuel use, it offers a dynamic blend of power and economy.





Well-thought Design: This design integrates tilt functionality, 360° rotation, and CDI ignition technology, with reverse gear engagement achieved through 180° rotation at the front end, ensuring operational flexibility and convenience.





Safety Guard: Equipped with an emergency stop switch and a safety lanyard, it also includes a clutch that halts propeller rotation during idling for enhanced safety. The air-cooled design with multiple ventilation holes ensures efficient heat dissipation, promoting stable performance and prolonged durability.





Premium Gift Selection: With its exceptional practicality, this product makes an ideal gift for friends and family, as well as an ideal choice for sailing enthusiasts and anglers.





Details



Ergonomic Handle: It provides a comfortable and secure grip. When not in use, the handle can be folded for easy storage and transport.



Humanized Handle: It is designed for a comfortable and firm hold, and can also fold away to simplify storage and transportation when not in use.





Spacious Fuel Tank: With a generous capacity of 0.34-0.4 gallons, this fuel tank minimizes the need for frequent refueling.





Application



It can be used for aquaculture, transportation, net fishing, bait fishing, outboard motor backup, and river cleaning and maintenance. It is suitable for inflatable boats, fishing boats, sailboats, small yachts, canoes, kayaks, flat-bottomed boats, rubber boats, and aluminum alloy boats ranging from 15 to 20 feet in length.

Notes

1. Please note that the driving speed will change due to different ship types, loads, and natural conditions.

2. High-temperature exhaust components may cause severe burns. Please do not touch them.

3. Please do not disassemble the host without authorization to avoid unnecessary damage. Please do not use it indoors or in enclosed spaces. Before long-term storage, the gasoline in the tank should be empty.The engine should be stored in a well-ventilated place and avoid direct exposure to sunlight.

4. Before use, please prepare enough fuel, bring life jackets, and other necessary tools(not included), and check if the outboard engine is installed correctly.

5. Please read the English manual carefully before use, paying particular attention to the safety instructions.

6. Please allow the slight color difference caused by the shooting light and 1-3 cm error due to manual measurement, and make sure you do not mind before ordering.
