SPECIFICATIONS



Battery type: Lead acid or lithium battery





Certification: CE,CE

Communicati on interface: USB/RS485/WiFi

Low voltage: Below 50Vac or 75Vdc

Features: Supports working without batteries,Supports feeding power to the grid function,parallel,with CT

Features2: Parallel version with CT

Features3: ecoworthy

Features4: mppt

Features5: hybrid inverter 48v

Features6: solar panel

Features7: split phase inverter

Features8: inversor hibrido 48v 110v 220v fase dividida

Features9: solar



Is Smart Device: Yes

Max MPPT Voltage: 500VDC

Maximum PV Array Power: 6000W*2

Model Number: Inverter 12KW

Noise: ≤60dB



Output Current: 2pole, 60A/60A(L1/L2)

Output Frequency: 50HZ 60HZ,50HZ/60HZ

Output Type: SINGLE

Output voltage waveform: Pure sine wave

Permitted parallel number: 1-6pcs

Rated input voltage: 120(L1/N, L2/N)/240Vac(L1/L2)

Size: 620mm*450mm*132mm

Weight: 27.5KG

communication interface: RS485/CAN

is_customized: Yes

solar system: split phase inverter 48v 110v
